QUADRANT

RECESSED - MODULAR

Characterised by advanced technical features

Light Source
- LED
Light Type
Light Style
- MODULAR
Related Files
- Datasheets
- Photometry

Specification Details

Mounting

Recessed

Housing

Fabricated Sheet steel body
Air handling frame (on request)

Photometrics and Optics

Direct
Microprismatic Lambent optic

Light Sources

LED : Square format boards
LED - Static White ( 3000K & 4000K )
LED - Tunable White ( 2700K - 6000K ) (On request)
CRI: 80 or 90

Installation

Lay in ceiling grid (Standard)
Ceiling System Compatibility
SAS, Armstrong, Burgess
Plasterboard solid ceiling

Electrical

Solid copper internal wiring to 3 or 5 pole terminal block
Fast-fit connector as standard

Colours

Factory proprietary White

1. Range: QUADRANT

2. Mounting options & Dimensional details

Recessed

3. Photometric Distribution

Recessed

4. Optics

D Microprismatic

5. Lamp Options

			Lamp			Dimensions	CCT	WEIGHT
Vers.	Code	Wattage	Lumen Output	L	W	H	CCT (K)	KG
R	39.840	39	4736	595	595	60	4000	5.2
R	18.840	18	2250	896	296	60	4000	4.8
R	23.840	23	3000	1196	296	60	4000	5.2
R	27.840	27	3500	1496	296	60	4000	5.6
R	VARIOUS	BESPOKE

All dimensions & weights stated above are nominal.

6. Ballast & Control

High frequency / Electronic

DALI Digital Addressable Lighting Interface

7. Colour

WHite

8. Emergency options ( Integral & Remote)

EM3 - 3Hr Maintained Emergency conversion.

ST3 - Self Test 3Hr Maintained Emergency conversion.

AD3 - Addressable 3Hr Maintained Emergency conversion.

(For specific fitment type, integral or remote, please contact the Phi technical department )
