MAX

FEATURE - ACCENT

For highlighting and artistic notes

Specification Details

Mounting

  • Track mounting
  • 3 Circuit

Housing

  • Housing: Die Cast aluminium
  • IP20
  • Vertical or Horizontal gear housing (please state requirement)

Photometrics and Optics

  • Direct
  • Facetted reflector
  • 12, 20, 30, 40 & 60 Degree beam

Light Sources

  • LED : COB
  • WATTAGES : 31w or 35w
  • CCT : 2700(K), 3000(K) & 4000(K)
  • CRI : >80 or >90

Installation

  • Track Adapter

Electrical

  • Integral HF Driver

Colours

  • White
  • Black
  • Silver Grey

1. Range: MAX

2. Mounting options & Dimensional details

3. Photometric Distribution

Direct 12 degree
Direct 20 degree
Direct 30 degree
Direct 40 degree
Direct 60 degree

4. Optics

5. Lamp Options

LampDimensions
VersCodeWattageCCT (K)DH
31.8303130009499
31.8403140009499
35.830353000115143
35.840354000115143
All dimensions & weights stated above are nominal.

6. Ballast & Control

High frequency Electronic

DALI Digital Addressable Lighting Interface

7. Colour

WHite
BLack
Grey

8. Emergency options ( Integral & Remote)

Not Available

9. Options & Accessories

V Vertical gear housing

H Horizontal gear housing

AGS Anti glare screen

VIS Visor

HCF Honeycomb filter

BND Barn doors

Additional Images

AGS
VIS
HCF
BND
